ASSA ABLOY DS6060P Curtain Dock Shelter Parallel
Secure efficient weather protection and a high tear-resistance with a ASSA ABLOY (formerly Crawford) mechanical-curtain dock shelter
The ASSA ABLOY DS6060P is a high-performance curtain dock shelter designed to accommodate a wide variety of vehicle heights and widths. Featuring a self-adjusting top section, it automatically adapts to different vehicle heights and movements, ensuring an optimal seal during loading and unloading.
As the vehicle reverses into the dock, the flexible side and top curtains create a secure seal, providing weather protection while improving working conditions and safeguarding goods. The curtain material is engineered for exceptional wear and tear resistance, ensuring long-lasting durability.
As the vehicle reverses into the dock, the flexible side and top curtains create a secure seal, providing weather protection while improving working conditions and safeguarding goods. The curtain material is engineered for exceptional wear and tear resistance, ensuring long-lasting durability.
Built for Efficiency and Durability
✔ Flexible and durable: Built-in springs allow the shelter to absorb minor impacts from misaligned vehicles without damage.
✔ Versatile and adaptable: Designed to fit a wide range of vehicle sizes, meeting diverse customer needs.
✔ High price-performance ratio: The preferred choice for the majority of European loading bays.
Innovative Curtain Fixation System
Unlike traditional mechanical dock shelters, the ASSA ABLOY DS6060P features a unique steel ball fixation system for the front curtains. This innovative design enhances tear resistance and eliminates weak points, ensuring a more durable and reliable solution compared to conventional screw or rivet fixations.
Environmentally Conscious Design
All ASSA ABLOY mechanical dock shelters can be equipped with additional features to improve energy efficiency and minimize draughts inside the building. These enhancements create a more comfortable and sustainable working environment.
ASSA ABLOY DS6060P Curtain Dock Shelter Parallel
BIM object
Collapsable frame
Frame parts of aluminium
Large sizes range
ASSA ABLOY DS6060P
- Product ID : DS6060P
- Normal height: 3200, 3400, 3600, 3800, 4000,4200, 4400, 4600 mm
- Normal width: 3200, 3250, 3400, 3450, 3500 mm
- Normal depth: 600, 900 mm
- Top curtain 1000, 1200, 1500 mm
- Side curtain: 600, 700 mm
- Curtain colour: black
- Parking guides: white, yellow
- Wall fixings: concrete, sandwich,light concrete, loadhouse, cavity, insulated panel
- Top and side curtains: double layer high quality polyester
- Thickness: 3,0 mm
- Weight Approx.: 3400 g/m²
- Continuous roof cover: one layer high quality polyester
- Thickness: 0,5 mm
- Weight Approx.: 680 g/m²
- Flammability all curtains: DIN 75200
- Product ID : DS6060P
